The Rutland ITS11204 is an adjustable size 2-4 concealed overhead door closer suitable for single action doors up to 1100mm wide or 80kg in weight. The ITS11204 features a cam and roller mechanism which can assist door sets meet the requirement of Approved Document M and BS8300 recommendations. This very slim, un-handed, EN2-4 tested product is suitable for a variety of metal and timber doors, and features in locations where accessibility and aesthetics are crucial, such as hospitals, care homes and schools. This closer is suitable for doors with a minimum thickness of 44mm, has adjustable closing speed and latch action and is supplied with matching arm and channel. The ITS11204 is CE marked, certified in compliance to EN1154, and has been fire tested to EN1634 for up to 60 minute timber fire doors when fitted with the IP.114 intumescent pack (supplied separately).
Specification :
- Finish: PVD Brass
- Power size: Adjustable EN 2-4
- Maximum door width: 1100mm
- Minimum door width: 850mm
- Minimum door thickness: 44mm
- Maximum door weight: 80kg
- CE Marked
- Certified in compliance with EN1154
- Fire tested to EN1634 for up to 60 minute fire doors when fitted with the IP.114 intumescent pack (supplied separately)
- Adjustable closing speed and latch action
