All Arrone AR3500 closers have adjustable power size 2-4 and are suitable for use on doors up to 1100mm wide and 80kg in weight. and are supplied with brackets for fig 1, fig 61 and fig 66 fixing. The AR3500 closer range is CE marked for Safety meeting European standards, is approved by Certifire, tested to BS EN 1634-1 and British Standard BS EN 1154.
The AR3500 can satisfy the opening force recommendations of BS 8300 and ADM when fitted in Fig 1 to a door with minimum width of 938 mm according to third party data. However other installed hardware, door seals and differential air pressure will affect the products as fitted performance meaning that the door closer alone cannot allow compliance to BS 8300 and ADM.
The Arrone AR3500 door closers are ideal for schools, nurseries, or any location where colour coding is required.
Specification :
- Finish: Green RAL6016
- Power size: Adjustable EN 2-4
- Maximum door width: 1100mm
- Maximum door weight: 80kg
- Suitable for fig.1, fig.6 & fig.61 mounting
- Features backcheck and delayed action
- Successfully fire tested to BS EN1634 for use on 30, 60 and 120 minute timber fire doors.
- Certified in compliance with EN1154
- CE Marked
- Certifire approved
